Brother TD-4520TN


Compact and dependable label & barcode printer

The Brother TD-4520TN is a professional desktop printer that merges robust construction with precise results. Offering 300 dpi print quality and supporting both thermal transfer and direct thermal technology, it produces crisp, durable labels up to 112 mm in width (usable 105.7 mm).

With print speeds up to 127 mm/sec (5 ips), downtime is minimized while productivity increases. Connection options include USB 2.0, Ethernet LAN (10/100 Mbps), and RS-232 serial. Supplied with Seagull BarTender UltraLite labelling software free of charge.

Ideal for printing labels on pallets, cartons, cardboard, glass, plastic, and metal. Supports a full range of 1D and 2D barcode types.

Why choose Brother TD-4520TN

High-resolution printing icon
High-resolution printing
300 dpi delivers sharp, easy-to-read text and barcodes.

Versatile media icon
Versatile media handling
Compatible with pallets, cardboard, plastics, metals, glass.

Connectivity icon
Flexible connectivity
USB, Ethernet, RS-232; supports ZPL/ZPL2, EPL, DPL.

Technical specifications

Printing technology Thermal transfer / Direct thermal
Resolution 300 dpi (12 dots/mm)
Max print width 105.7 mm (usable up to 112 mm)
Max print speed 127 mm/sec (5 ips)
Max media width 112 mm
Max print length 11,430 mm (450 in)
Supported barcode types Linear: Code128, EAN-8/13, ITF-14, Code39, MSI, POSTNET, LOGMARS; 2D: PDF417, DataMatrix, QR Code, Aztec, GS1 DataMatrix etc.
Connectivity USB 2.0, USB host, Ethernet LAN, RS-232C serial
Memory 64 MB SDRAM, 128 MB flash
Software Seagull BarTender UltraLite included
Dimensions (W x D x H) 204 × 280 × 177.5 mm
Weight 2.5 kg
Operating temp./humidity 5 °C to 40 °C / 25–85% RH (non-condensing)
